Advantages of Talpa wire ropes
Extra strength
Reduced wear of traction elements
Multiple impact strength and transverse load resistance
Increased wear resistance
Special design
EN 12385-4
(6x36WS-IWRC)
(6x36WS-IWRC)
1. Diameter 39,0 mm
2. Weight 6,99 kg/m
3. T.S. 1770 N/mm2
4. Minimum breaking force 1160 кН
2. Weight 6,99 kg/m
3. T.S. 1770 N/mm2
4. Minimum breaking force 1160 кН
Talpa 836K
(8xK36WS-IWRC)
(8xK36WS-IWRC)
Comparison of wire ropes
1. Diameter 39,0 mm
2. Weight 6,72 kg/m
3. T.S. 1770 N/mm2
4. Minimum breaking force 1082 кН
2. Weight 6,72 kg/m
3. T.S. 1770 N/mm2
4. Minimum breaking force 1082 кН
Talpa 636K
(6xK36WS-IWRC)
(6xK36WS-IWRC)
1. Diameter 39,0 mm
2. Weight 6,53 kg/m
3. T.S. 1770 N/mm2
4. Minimum breaking force 972 кН
2. Weight 6,53 kg/m
3. T.S. 1770 N/mm2
4. Minimum breaking force 972 кН
Steel wire ropes
Talpa 636K
6х36 + 7х7
Diameters: from 36,0 to 68,0 mm
Breaking load: from 909 to 3 120
Submit a request
We will contact you to clarify the details
Application of Talpa wire ropes
Underground mining
Surface mining
Polymer-sheathed wire ropes
For maximum surface protection of steel ropes, we have designed wire ropes with a polymer sheath covering outer strands.
For coating, we use an ultra-strong polymer that reliably adheres to the rope surface and retains its structure for a long time during operation.
Thanks to their design, Talpa wire ropes have longer operational life compared to standard ropes, which significantly reduces the number of rope replacements and leads to less maintenance activities and lower cost of equipment ownership.
For coating, we use an ultra-strong polymer that reliably adheres to the rope surface and retains its structure for a long time during operation.
Thanks to their design, Talpa wire ropes have longer operational life compared to standard ropes, which significantly reduces the number of rope replacements and leads to less maintenance activities and lower cost of equipment ownership.
Manufacture of guy ropes
In addition to steel ropes, Severstal Wire Ropes produces guy ropes structures and products that are used on mining excavators. We produce guy ropes for almost all models of domestic and foreign excavators, including walking excavators - draglines. In contrast with comparable products, the products manufactured by Severstal Wire Ropes provide adjustable stretch, which reduces time necessary for installation of guy ropes on an excavator. Our own engineering department and wide experience in this area allow us to manufacture individual products for a specific client's request.
Manufacture of guy ropes
In addition to steel ropes, Severstal Wire Ropes produces guy ropes structures and products that are used on mining excavators. We produce guy ropes for almost all models of domestic and foreign excavators, including walking excavators - draglines. In contrast with comparable products, the products manufactured by Severstal Wire Ropes provide adjustable stretch, which reduces time necessary for installation of guy ropes on an excavator. Our own engineering department and wide experience in this area allow us to manufacture individual products for a specific client's request.
Mesh grips for steel wire ropes
For easier installation of a new rope, we offer our customers special steel wire mesh grips. They are tightened securely on the free ends of the old rope and the new one connecting them firmly. After that, the rope is installed on the winding hoist drum.
Services
Pre-stretching
- Lower residual elongation
- Higher modulus of elasticity
- Much lower rotation moment
- Efficient performance
Electromagnetic inspection
- Nondestructive inspection is the only test providing total evaluation of damage level and residual operation time of a wire rope.
- Nondestructive inspection allows to detect reduction of cross-sectional area of a wire rope, external and internal local damages and their location.
Tests
Tensile testing machine for wire ropes of all constructions with capacity up to 500 tons.
Support for rope installation
For the rope installation to be carried out in compliance with all process procedures, at the client's request, experts of Severstal Wire Ropes visit the client and provide support for the rope installation before it is put into operation.
Get the catalogue
Leave a request and we will send you the catalogue with Talpa steel wire ropes by e-mail
By clicking the "Get the catalogue" button, you agree to the processing of personal data and the privacy policy
Service Center
From our experience, the better is the fit of a rope the longer is its service life. Specialists of the Service Center have already helped dozens of clients with selection and maintenance of wire ropes on different equipment from cranes to drilling rigs. Factors such as area of application, equipment features, operating conditions, etc. are taken into consideration during their work with new sites.
Specialists of the Service Center provide the following rope related services:
Specialists of the Service Center provide the following rope related services:
- Rope selection for specific working conditions.
- Advice on application features, rope installation and operation.
- Designing special rope constructions (in cooperation with Technological Service).
- Supply of pilot batches of products.
- Selection of terminations and fasteners.
- Technical support for rope installation at a client's site.
- Control over rope operating life and calculation of guaranteed service life
- Trainings.
Company introduction
АО "Severstal Wire Ropes" (part of the Severstal-metiz group of companies) is a Russian manufacturer of steel wire ropes. The product range of the company includes more than 100 types of wire ropes produced in accordance with domestic and international standards (EN and API).
Customers choose our special wire ropes for:
Customers choose our special wire ropes for:
- Oil and gas producing industry
- Mining
- Production and maintenance of elevators
- All types of cranes used in any manufacturing industry
- Cableways
- Electricity supply industry
For each of these applications, we produce a separate product line of special ropes with unique technical performance and design.
For mining, we produce 6-strand, 8-strand and multi-strand Talpa® special wire ropes with compacted outer strands and polymer filling of the external and outer strands. Thanks to their design, Talpa wire ropes are much stronger and have extended operational life compared to standard and out-dated ropes. This allows our customers to significantly reduce the number of wire rope replacement operations and cut the cost of servicing excavators and mining systems.
The Quality Management System of Severstal Wire Ropes is certified according to international standards ISO 9001:2015, 45001:2018 и 14001:2015. All manufactured products comply with Russian and European standards and have necessary quality certificates.
For mining, we produce 6-strand, 8-strand and multi-strand Talpa® special wire ropes with compacted outer strands and polymer filling of the external and outer strands. Thanks to their design, Talpa wire ropes are much stronger and have extended operational life compared to standard and out-dated ropes. This allows our customers to significantly reduce the number of wire rope replacement operations and cut the cost of servicing excavators and mining systems.
The Quality Management System of Severstal Wire Ropes is certified according to international standards ISO 9001:2015, 45001:2018 и 14001:2015. All manufactured products comply with Russian and European standards and have necessary quality certificates.
